Top Mounted Magnetic Level Indicator

Top Mounted Magnetic Level Indicator

Simple principle of mechanics and magnetism harnessed to offer an absolutely safe, reliable and trustworthy level indicator for dangerous and toxic liquids under high pressure and temperature. Due to magnetic attraction, the magnet on the float stem and the magnetic follower are coupled and move in union. As the float moves along with the liquid, the follower also moves inside the glass tube, and the position of the follower can be read against the scale.

Liquids Acids/Alkalies/Solvents/Oils Lubricants/Liquid Gases stored in Under ground or Over Ground Tanks
Density / Sp. gravity Minimum 0.6
Viscosity Upto 250 cp
Design Temperature Up to 350°c
Design Pressure Up to 7 Kg/cm²
Tank Hight (Range) Up to 3000 mm
Material of wetted Parts MS/CS/SS304/SS304L/SS316/SS316L/PTFE Lined SS/PVC/PP
Connection Flanged to ASA/BS/DIN/Triclover Minimum Nozzle size required 4" NB for liquids below 0.8 Density
