Glass Tube Rotameter
Glass Tube Rotameter
Our Products
It is an instrument used to measure instant flow rate of Liquids and Gases. It is installed in the pipe line vertically upward with flanged or screwed connection.
| Fluid | Liquids & Gases |
| Density / Sp. Gravity | Up to 2.95 |
| Viscosity | Up to 200 cp |
| Design Temperature | Up to 150°C |
| Design Pressure | Up to 15 Kg/cm² Depending on Model |
| Measuring Range | 2.5 to 40,000 LPH of Water/Liquid & 0.1 to 750 Nm³/hr of Air/Gas at NTP |
| Line Size | Up to 4" NB |
| Available Materials | MS/CS/SS304/SS304L/SS316/SS316L/PTFE lined MS or SS |
| Connection | Flanged to ASA/BS/DIN/ Tri clover Standard Screwed to BSP/NPT(M/F) |
| Accuracy | ±2% of FSD & ±1.5% on request |
